RRK Series
Explosion-proof EXE
- Small volume flows in rooms and workspaces
- IP54 - explosion tested
Model: RRK 180 Ex / RRK 200 Ex / RRK 250 Ex
Order Code: See Technical Data, below, for Order Codes
Features
• Very compact in design and low installation cost through straight air flow
• Installation in any position
• Explosion proof E Exe II 2D
• Increased safety to DIN EN 60079-0, 60079-7, 1127-1, 14986
• Casing and impeller made from impact resistant, anti-static polymers
• Reducers are available for RRK 180 to suit 100mm and 125mm ducts
Accessories
• Speed controllers
• Mounting Bracket
• Reducers
| Model | Code | mm | A | W | Hz | Phase | V | l/s | m3/h | Pa | RPM | dBA | Kg | Temp Class | IP |
| RRK 180 Ex | ALV42359 | 180 | 0.25 | 50 | 50 | 1 | 230 | 81 | 290 | 200 | 2780 | 48 | 3.0 | T1-T4 | IP54 |
| RRK 200 Ex | ALV42263 | 200 | 0.92 | 200 | 50 | 1 | 230 | 156 | 560 | 320 | 2860 | 55 | 5.5 | T1-T3 | IP54 |
| RRK 250 Ex | ALV42309 | 250 | 1.40 | 300 | 50 | 1 | 230 | 269 | 970 | 370 | 2860 | 59 | 7.0 | T1-T3 | IP54 |
